Frequency Range

1~200MHz

Output Type

CMOS

Output Load

15 pF

Supply Voltage

1.8±10%V、2.5±10%V、3.3±10%V

Frequency Stability

± 20 ppm , or specify

Operating Temperature Range

-40~+85 ℃ , or specify

Storage Temperature Range

-40~+125 ℃

Current Consumption

10 mA Max.

Symmetry

45 ~55 %

Start-up Time

3.0 ms Typ

Rise time( Tr )/Fall time ( Tf )

8 ns Max （ fo ≤ 40 MHz）

5 ns Max（ fo > 40 MHz

Enable Function

70%(Min.)of VDD to Enable Output

Disable Function

30%(Max.)of VDDto Disable Output

Aging ( at 25℃)

± 3 ppm / year Max.

Spread type

Center spread、Down spread
